Recycled Paper Making Machine

This machine could make kraft paper ,fluting paper and corrugated paper rolls from recycled waste carton paper.

PRODUCT DETAILS

This machine could make kraft paper ,fluting paper and corrugated paper rolls from recycled waste carton paper.

PRODUCT DETAILS

Recycled Paper Making Machine

This machine could make kraft paper ,fluting paper and corrugated paper rolls from recycled waste carton paper.


Recycled paper making machine used in kraft paper mill plant is a machine that converts waste carton cardboard into paper pulp and then into paper rolls. through the processes of filter dehydration, mechanical extrusion dehydration and drying. The raw materials used are : waste paper boxes, wood pulp pulleys, etc. It can produce kraft paper, shopping bag paper, food wrapping paper , fruit wrapping paper, etc. Reliable quality, stable performance, convenient operation, energy saving and environmental protection, it is an ideal product in papermaking machinery .


Paper machine technical description:

1. main products:

Box board, kraft paper , etc.

2. Quantitative:

100 300 g/

3. Equipment form

Four-yuan network multi-cylinder

4. Yield:

20T/24h

5. Clean paper width:

1575-1650mm _

6. Design Speed:

120m /min

7. Transmission speed:

40-100 m/min

8. Roll balance:

Grade G2.5

9. Dryer Balance:

G level 4

10. Roller:

G 1.6

11. transfer method:

AC motor and digital display division frequency conversion speed regulation drive

12. Arrangement:

Left and right mobile phones (selected by the user)

13. gauge:

240 0mm

1 4. Large item name 1

Dryer: Ø 150 0mm × 16

1 5. Bulk name 2

Cage : Ø 1500 mm × 4 _
