High speed model
High speed model.
Machine Details
Jumbo parent roll width | 1600mm |
Maxi Parent roll diameter | 1400mm |
Maxi Finished paper roll diameter | 1400mm |
Slit width | ≥40mm |
Paper gsm | 80-600gsm |
Power | 15kw |
Up paper mode | Hydraulic |
Brake | Magnetic powder brakes automatically |
Blade adjustment way | CNC tool setting |
Unload | Hydraulic cutting |
Speed | 350m/min |
Operator | 1 |
Dimension | 3000mm*1800mm*1500mm |
Weight | 2 tons |
Packing Size | 3.9*1.6*1.7m(L*W*H) 2.8*1.7*1.7m(L*w*h) Total size:18 m3. |
